YSVV800F New Medical Vein Viewer System Vein Illuminator Price Portable Vein Finder

FOB Reference Price:Get Latest Price
$1,460.00 - $1,780.00 / Set | 1 Set/Sets (Min. Order)
Report Suspicious Activity
Overview
Quick Details
Place of Origin:
China
Brand Name:
YSENMED
Model Number:
YSVV800F
Type:
Blood Analysis System
Instrument classification:
Class II
Name:
Vein Finder/Detector
Light type:
NIR
Infrared wavelengths:
940nm & 850nm
Basic mode:
Yes
Projection colors:
Green, White
Photo & Storage:
16GB
Infrared radiation value:
≤0.6mW/cm2
Image resolution:
≤8 mm
Optimal distance:
210mm±30mm
Net weight:
350g
Supply Ability
Supply Ability:
1000 Set/Sets per Month Vein Finder/Viewer
Packaging & Delivery
Packaging Details
Standard export wooden package for Vein Finder/Viewer
Port
Guangzhou

YSVV800F New Medical Vein Viewer System Vein Illuminator Price Portable Vein Finder

Product description

Table stand.jpg

Application:



With the gradual improvement of people's living standards, the rate of obesity also increases daily. Since it is hard to locate and trace veins of the obesity and some infants, venipuncture has become an increasingly challenging field for medical practitioners and brings great pains to the patients during injection or blood-drawing. It is not surprising if a medical practitioner cannot find blood veins accurately. The rate of successful venipuncture for the first time is as law as 70%.To help medical personnel to locate blood veins easily, Yueshen has developed this Projection Vein Finder.

PVF is designed on the principle that hemoglobin has a stronger absorption under near-infrared light. After the photosensitive element acquires the infrared image of the skin, the product maps the outline of the vein through a series of digital image processing. Then, the projector projects the image on the surface of human skin to restore vein distribution. PVF is easy and simple to operate. Qualified medical personnel can easily locate for venipuncture by observing the vein image.







Specification:



YSVV800F
Configurations YSVV800F
Light typeNIR
Infrared wavelengths 940nm & 850nm
Basic modeYes
Pediatric size  Yes
Adjustable brightnessYes
Projection colors *Green, White
Depth recognition *No
Photo & Storage *Yes, 16 GB
USB output *Yes
Infrared radiation value≤0.6mW/cm2
Image resolution854*480pixel
Depth of investigation≤8 mm
Optimal distance 210mm±30mm
Net weight *350g
Product volume *228*63*62mm
Built in rechargeable battery Yes
standby time *≤4.5h
charging time *≤3.5h
Stand  *Optional







Comparison Table
Configurations YSVV800FYSVV500S
Light typeNIRNIR
Infrared wavelengths 940nm & 850nm940nm & 850nm
Basic modeYesYes
Pediatric size  YesYes
Adjustable brightnessYesYes
Projection colors *Green, WhiteGreen, White
Depth recognition *NoYes
Photo & Storage *Yes, 16 GBNo
USB output *YesNo
Infrared radiation value≤0.6mW/cm2≤0.6mW/cm2
Image resolution854*480pixel854*480pixel
Depth of investigation≤8 mm≤8 mm
Optimal distance 210mm±30mm210±30mm
Net weight *350g430g
Product volume *228*63*62mm213*65*62mm
Built in rechargeable battery YesYes
standby time *≤4.5h≤2.5h
charging time *≤3.5h ≤4h
Stand  *OptionalTable stand or floor stand selectable



Product Display


YSVV500S:

YSVV500S 4
